1. Power On

• Press and hold the Power/Mode button to turn on the device.

• The LCD screen will light up when it’s ready.


2. Select Measurement Unit

• Long press the Mode button to switch between yards (YD) and meters (M).

• Choose your preferred unit of measure.


3. Choose a Mode

Press the Mode button briefly to cycle through the 5 modes:

1. Line Distance Mode – Measures straight-line distance.

2. Horizontal Distance Mode – Measures horizontal distance only.

3. Vertical Distance Mode – Measures vertical height only.

4. Height Difference Mode – Calculates elevation difference between two points.

5. Golf Mode – Activates slope compensation and flagpole-locking features.


4. Use Slope Compensation (Golf Mode)

• When in Golf Mode, the rangefinder automatically adjusts distance based on uphill or downhill slopes.

• This gives you a true play distance instead of just raw yardage.


5. Lock Onto the Flag

• Aim the crosshairs at the flag.

• Press and hold the Power button to scan.

• The device will vibrate once it locks onto the flag (Flagpole Locking Function).


6. Read the Display

The LCD will show:

• Distance to the target (adjusted if slope mode is on).

• Angle of inclination (+85° to -85°).

• Lock confirmation (if using Flag Lock).


7. Adjust Your View

• Field of view: 6.5° with 6X magnification.

• Objective lens: 20mm, eye relief: 16mm.

• Hold steady for the clearest reading.


8. Quick Tips for Best Use

• Range acquisition takes 0.3–0.8 seconds.

• Keep your hand steady or use both hands for stability.

• Avoid aiming at reflective or moving objects for more accuracy.

• Works best within 5–750 yards.


9. Charging the Device

• Recharge using the USB Type-C cable included.

• A full charge ensures consistent performance on the course.


• Golf Rangefinder (built-in battery)

• Protective Carrying Case

• USB Type-C Charging Cable

• Wrist Strap/Lanyard

• Cleaning Cloth for Lens

• User Manual
